Silicone vacuum hose is extruded from silicone rubber with unreinforced construction. Silicone rubber has a lot of good properties, including low chemical reactivity, low thermal conductivity, high thermal stability and excellent resistance to oxygen, ozone and UV. All these properties contribute to good performances within extreme temperatures.
Product parameters
Inner: Only silicone, no reinforcement
Temperature: -40℃ to +200℃
Scope of application
1. Replace any rubber hose in your engine bay.
2. Installation of turbo parts, like your boost gauge, blow off valve or waste-gate.
3. Improve the appearance of your engine.
| Specification - silicone vacuum hose | ||||
| Item No. | I.D. | Thickness | Length | |
| inch | mm | mm | mm | |
| HYSVH001 | 1/2 | 13 | 4 | 1000 |
| HYSVH002 | 5/8 | 16 | 4 | 1000 |
| HYSVH003 | 3/4 | 19 | 4 | 1000 |
| HYSVH004 | 7/8 | 22 | 4 | 1000 |
| HYSVH005 | 1 | 25 | 4 | 1000 |
| HYSVH006 | 1-1/8 | 28 | 4 | 1000 |
| HYSVH007 | 1-1/4 | 32 | 4 | 1000 |
| HYSVH008 | 1-3/8 | 35 | 4 | 1000 |
| HYSVH009 | 1-1/2 | 38 | 4 | 1000 |
| HYSVH010 | 2 | 51 | 5 | 1000 |
| HYSVH011 | 2-1/2 | 63 | 5 | 1000 |
| Notes | The thickness, length and color can vary according to your requirement. | |||
